MaPixel Blinder - 36x3w warm white or 36x10w RGBW LEDs
|
The MaPixel Blinder features 36x3w, Cree(2800k), Warm white or 36x10w Quad-color LED, which provides excellent effects
The MaPixel Blinder a truly versatile LED system that projects 4.5 degree narrow beams of light, provides warm washes, makes instant audience blinders, and displays text and vivid animated graphics. Powerful Cree LEDs partnered with a flexible software system generate stunning pixel mapping effects. A smooth dimming curve with a color temperature makes it perfect for live events, broadcast, studio, theatre, and touring applications.
Features:
1. LED Video Wall Cabinets design, Quick Easy Installation, Die-cast Aluminums .
2. Display Letter, Alpha Number, Pixel Mapping effects
3. Warm white up to 2800K Warm White,3W and Quad-color, 10W are available) ,
4. Smoothly Selectable Dimming Curve , Flicker Free/ Ultra Fast strobe
5. Beam Angle: 4.5 degree
6. Built-in effects triggered by DMX, Each of the 36pcs LEDs can be individually controlled via DMX-512. Furthermore, great internal automatic programs are available in the master / slave mode as well as triggering from Music to light.
Specifications:
LED Source:
Source Type: (36) 3W, Warm White 2800k/ Cool White or 10W RGBW 4-in-1 LEDs
, 50,000 hours lifetime
Illuminance (total): 7,900 lux @ 5 m for (36) 3W
EFFECTS
Display Letter, Alpha Number, Pixel Mapping effects
Built-in effects triggered by DMX,
Individual Pixel Control
Strobe and Selectable Dimming Curves
CONTROL / CONNECTIONS
(4) DMX Channel Modes (1/4/10/36/40 chs)
4 Button Touch Control Panel
LCD Menu Display
3pin or 5pin DMX In/Out
powerCON Power In/Out
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
150W Max Power Consumption
-13°F to 113°F (-25°C to 45°C)
APPROVALS / RATINGS
CE | RoHs Compliant | IP20
SIZE / WEIGHT：
Length: 19.68 (500mm)
Width: 19.68 (500mm)
Vertical Height: 3.15 (80mm)
Weight: 18.74lbs. (8.5 kg)
|
|
|
|
|
|
